Footprint

Top-down outline drawn to scale from factory dimensions. Compare footprints side by side on the compare page.

SS-240-1A

1-Person Spa

In stock

Dimensions (L × W × H): 71″ × 42″ × 32″
Dry weight: 350 lbs
Water capacity: 150 gal
Jets: 16
Voltage: 240V
Circuit: 50 amp
Total watts: 7,350
Pump: 3 HP
Heater: 5.5 kW titanium
Controls: Balboa Control System
Seating: 1 person

Spec sheet (print)Image pack (4)

Installation planning

Electrical. Requires a dedicated 50A 240V GFCI circuit, installed by a licensed electrician.
Pad. Level, reinforced surface at least 42″ × 71″, with 18–24″ of service clearance on the equipment side.
Weight. 350 lbs dry, roughly 1,800 lbs filled and occupied (estimate).
Delivery. Ships curbside LTL on a pallet. Freight quoted with dealer pricing on request.

No retail pricing is shown on this catalog. Submit a request sheet for dealer pricing, freight, and availability.

Overview

1-person capacity, 42 by 71 inch footprint, 16 jets, 240V. Ships with Balboa controls, ozone sanitation, LED lighting. Compact footprint fits decks, patios, and small yards where a full-size shell will not. UV-rated cover and steps included.
